Silicone Rubber Thermal Imager Heater

Silicone Rubber Heater can be manufactured from etched foil or from resistance wire as a wire wound circuit. The circuit pattern is vulcanized between two layers of silicon rubber and can be easily mounted to heat sinks or devices that need to be heated.
Silicone rubber's flexility can make your Silicone Rubber Heater in the shape of flat, spiral wrap, blanket, and molded to shape. Silicon rubber heater can be supplied with thermistors , thermostats, thermal fuses and thermocouples.
Silicone rubber's flexility will assemble the heater to your application through the process of vulcanization and the use of silicone and pressure sensitive adhesives.

Benefits

Heater for Medical Device:
Excellent choice for heaters that require multi-zoned wattages or heaters that have many holes or cutouts:
- Offers excellent circuit repeatability.
- Elimination of edge loss due to compensation using distributed wattage.
- Etched foil provides options for variable watt density and complex heat patterns.
- Etching circuits is an efficient means for manufacturing in high quantities.
- Foil thickness ranges from .0005” to .004” depending on your required resistance.
- Different foil material types can be used depending on the heater resistance needed.
- Etched designs are excellent for applications requiring watt densities greater than 5 watts/in2.

Typical Application
- CPAP device
- Ultrasonic cleaner
- Medical analyzer
- Thermal Imaging system
- CT apparatus
- Injection syringe
- Other place need to heating

Specifications

Power Source: Electric
Voltage: 12-480V
Power : ≤ 3W/cm2
Maximum size: 500mm*1000mm
Thickness:1-1.5mm
Recommended working temperature:≤200℃
Color: Brown
Warranty: 1 Year
Insulation resistance: 1000V,≥100MΩ
Certification: ISO9001, CE, Rohs, UL
Application: as customer’s need

Accessories optional
